- Stock: 10
- Model: 1005003041162890
- Weight: 49.00kg
- Dimensions: 48.00cm x 31.00cm x 51.00cm
- SKU: 1005003041162890
HD11300 multi-channel power amplifier technical parameters:
Number of channels: 11 channels.
Output power: (ELA 1kHz 8 Ohms): 350 watts.
Output power: (ELA 1kHz 4 Ohms): 450 watts.
Output power: (FTC 20-20kHz 8 Ohms): 300 watts.
Output power: (FTC 20-20kHz 4 Ohms): 400 watts.
Input sensitivity: (rated power): 1.6 Volts.
Phase response: +5 to -15 (20Hz-20kHz, 1 watts).
Signal to noise ratio: 110dB.
Total harmonic distortion: (THD) ≤0.09% (FTC, 20Hz to 20kHz); 0.005% (ELA, 1kHz).
Load impedance range: 4 to 16 ohms.
Frequency response: 5Hz to 100kHz, FTC +0-3dB.
Input impedance: 28k ohms.
Damping coefficient: ≥180.
Trigger input: 12 Volts Trigger.
Power consumption: 4000 watts.
Voltage: 220 VAC 50Hz.
Size: 430x255x460mm( WxHxD).
Net weight: 43kg.
Shipping weight: Volume: 49kg.
