- Stock: 21
- Model: 32813851658
- Weight: 1.00kg
- Dimensions: 15.00cm x 10.00cm x 5.00cm
- SKU: 32813851658
WE HAVE THREE CHOICES FOU YOU, PLEASE CHOOSE WHTA YOU WANT.
Parameters:
Dimension:127*82*40 mm
Weight: 400g
Output Power ：400W (with PFC PF ＞0.98)
Output Noise: Less than 150mv
Output Voltage Adjustment Range: 10%
Enter-wire Stability: ±0.5%
Input Voltage: 88-264VAC
Attack time: 2s
Rise time: 500ms
Hold time: 20ms
(with 230VAC input voltage and full load output )
Pressure Resistance: Input-ouput 1.5KVAC ; Input-enclosure1.5VAC ; Output-enclosure : 500VAC
Insulation Resisitance: Input-output,Input-enclosure 500VDC/100MΩ
Working Tamp: -20°C~60°C,20%~90%RH Humidity
Storage Temperature: -40°C ~60°C
Protection Functions: Overcurrent,Overpower,Overvoltage,Overheat.
Safety Standards: GB4943,UL60950,EN60950
This form is for customers to better understand our products. If you want to know more details or purchase our products, please enter the link of the products.
|
Number |
Picture |
Name |
Power |
Output Voltage |
Price |
Link |
|
G-001 |
|
2*100W TAMP Dual Channel Class-D High-power HIFI Amplifier Board Fever |
100/72W |
15-36V |
43$ |
G-001 |
|
G-002 |
|
QUEENWAY 2200W High-power HI-FI Special Amplifier Switching Power Supply |
2200W |
+85V -80V +-12V +12V |
150$ |
G-002 |
|
G-003 |
|
200W TAMP Class-D HiFi Digital Audio Amplifier Board Car Subwoofer |
200W |
15-36V |
50-60$ |
G-003 |
|
G-004 |
|
2*15W Dual Channel TA2024 Stereo HiFi Class D Digital Power Amplifier Board |
15/10W |
12V |
28$ |
G-004 |
|
G-005 |
|
PFC Dual Output 36V/9A 12V/2A , 24V/13.5A 12V/2A 350W HI-FI Digital Amplifier Switching Power Supply |
350W |
36V/12V/24V |
39$ |
G-005 |
|
G-006 |
|
2*300W Dual Channel TAS5630B Class-D Digital Power Amplifier Board High Power HiFi Amplifier Board Fever |
300/133W |
48V |
77$ |
G-006 |
|
G-007 |
|
400W Mono Class-D Digital Audio Power Amplifier Board Subwoofer High Power HiFi Amplifier Board |
400/294W |
36V |
70$ |
G-007 |
|
G-008 |
|
600W Mono Class-D Digital Audio Power Amplifier Board Subwoofer High Power HiFi Amplifier Board |
600/350W |
48V |
84$ |
G-008 |
|
G-009 |
|
2*160W Dual Channel TDA7198E Class-D Digital Power Amplifier Board high Power HiFi Amplifier Board |
2*160W |
36V |
40$ |
G-009 |
|
G-010 |
|
6*100W DC 36V TDA7498 Class-D High-power 5.1 Amplifier Board |
6*100W |
14-39V |
75$ |
G-010 |
|
G-011 |
|
2*25W Dual Channel TDA7492 Class-D HiFi Digital Audio Amplifier Board Fever |
2*25W |
16V |
31$ |
G-011 |
|
G-012 |
|
800W LLC Digital Switch Power Supply Hi-Fi Amplifier Power Supply +/-10V/~+/-80V*2Can be Customized 110V/120V 220/230/240V |
800W |
See the details |
61.8-68$ |
G-012 |
|
G-013 |
|
2*250W Dual Channel Class-D Digital Power Amplifier Board IRS2092 High Power HiFi Amplifier Board |
2*250W |
50V |
64$ |
G-013 |
|
G-014 |
|
QUEENWAY 1500W/1000W HIFI Amplifier Switching Power Supply High-power |
100/1500W |
75V |
58-81.5$ |
G-014 |
|
G-015 |
|
PFC Dual Output 48V,7.8A 12V,2A/36V,10.5A 12V,2A/24V,15.5A 12V,2A 400W HI-FI Digital Amplifier Switching Power Supply |
400W |
12V/24V/36V/48V |
41$ |
G-015 |
|
G-016 |
|
4*100W Vehicle Audio Amplifier Board HiFi Class D TDA7498 Fever Audio Power Amplifier |
4*100W |
36V |
57$ |
G-016 |
|
G-017 |
|
2*400W Dual Channel Class-D Digital Power Amplifier Board High Power HiFi Amplifier Board |
2*400W |
48V |
84$ |
G-017 |
|
G-018 |
|
2*500W Dual Channel Class-D Digital Power Amplifier Board High Power HiFi Fever Amplifier Board |
2*500W |
50V |
112$ |
G-018 |
|
G-019 |
|
QUEENWAY 380V input 24V / 14.5A output 350W switching power supply 215 * 115 * 50 adapter |
350W |
24V |
50.99$ |
G-019 |
|
G-020 |
|
QUEENWAY with PFC Output 32V,12A / 36V,11A / 48V,8.3A 400W HI-FI Digital Amplifier Switching Power Supply |
400W |
88-264V |
39$ |
G-020 |
|
G-021 |
|
Dual Output 48V,6.5A 12V,2A / 36V,9A 12V,2A / 24V,13A 12V,2A 350W HI-FI Digital Amplifier Switching Power Supply |
350W |
88-264V |
25$ |
G-021 |
|
G-022 |
|
QUEENWAY PFC 48V/8.3A 400W HI-FI Digital Amplifier Switching Power Supply Overall Dimensions 127mm * 82mm * 38mm |
400W |
48V |
39$ |
G-022 |
|
G-023 |
|
LLC Resonant Soft Switching Power Supply 600W +-55V the Voltage Can be Customize Regulated Output |
See the details |
±55V |
59-65$ |
G-023 |
|
G-024 |
|
Dual 48V 300W High Power Digital Soft Switching Power Supply Regulated Output Use LLC Resonant Half Bridge Topologyv |
See the details |
48V/12V |
57-63$ |
G-024 |
|
G-025 |
|
QUEENWAY 24V/2.5A 60W HI-FI Digital Amplifier Switching Power Supply Suitable For TPA3116 TDA7492 Etc Chips |
60W/100W |
100-240V |
12.5$ |
G-025 |
|
G-026 |
|
PFC Dual Output +-24V,8A/36V,5.5A/42V,4.8A/48V,4.2A/55V,3.6A/60V,3.3A Adapter Digital Amplifier Switching Power Supply |
380W/400W |
88-264V |
45$ |
G-026 |
|
G-027 |
|
QUEENWAY Dual Output +15V/2.6A -15V/2.6A 80W HI-FI Amplifier Switching Power Supply Suitable For LM1875 TDA2030A |
80W |
88-264V |
17$ |
G-027 |
|
G-028 |
|
QUEENWAY Dual Output +12V/3.5A -12/3.5A 80W HI-FI Amplifier Switching Power Supply Suitable For LM1875 TDA2030A |
80W |
88-264V |
17$ |
G-028 |
|
G-029 |
|
24V/8.3A 200W Digital power amp dedicated switching power supply tiny size low noise enough power 110 * 65 * 35 adapter |
200W |
88-264V |
24$ |
G-029 |
|
G-030 |
|
QUEENWAY 110 / 220V Input 36v 10A 5V 60A 48V 7.3A 12V 29A 24V Switching adapter Security Billboard Display Power Supply |
350W |
110/220V |
33$ |
G-030 |
|
G-031 |
|
2*1200W Dual Channel Class D HiFi Digital Power Amplifier Board High Power |
2*1200W |
96V |
281$ |
G-031 |
|
G-032 |
|
2000W HiFi Class D Digital Power Amplifier Board high power Subwoofer suit for Stage and KTV |
2000W |
DC±55-85V |
250$ |
G-032 |
|
G-033 |
|
500W Step-up Module DC-DC12V Step-up 24V 48V HIFI Power Supply Vehicular Step-up Board High Power |
500W |
12V |
45$ |
G-033 |
|
G-034 |
|
300W Step-up Module DC12V for 24V 48V HIFI Power Supply Vehicular Step-up Board High Power |
300W |
24V/30V/36V/48V |
35$ |
G-034 |
|
G-035 |
|
Queenway CRS8670 APT-X Lossless 4.0 Wireless Vehicular Bluetooth Audio Receiving Board 12V Stereo Headphone Amp |
See the details |
See the details |
33$ |
G-035 |
|
G-036 |
|
HiFi Wireless Bluetooth Radio Receiving Board APT-X Module Receiving Board BT4.0 Stereo |
See the details |
12V |
28$ |
G-036 |
|
G-037 |
|
QUEENWAY DC25V/4A*2+DC15V/50mA*2 200W Digital Amplifier Switching Power Supply Board 3 Pin Plug AC220V input |
200W |
See the details |
28$ |
G-037 |
|
G-038 |
|
2*2W 12V PAM8803 Dual Channel Mini HiFi Digital Power Amplifier Board Stereo |
2*2W |
12V |
19-36$ |
G-038 |
|
G-039 |
|
Mining Power Supply 1600W 12V Switching High Quality Mining Power Suppluy |
1600W |
10V |
95$ |
G-039 |
|
G-040 |
|
QUEENWAY PFC 24V,14.5A / 36V,9.5A 350W HI-FI Digital Amplifier Switching Power Supply |
350W |
24V/36V |
37$ |
G-040 |
|
G-041 |
|
2*200W TAMP Dual Channel Class D HiFi Digital Power Amplifier Board High Power Stereo |
2*200W |
36V |
58$ |
G-041 |
|
G-042 |
|
60W 12V Single Channel Class-D TPA3118 Digital Amplifier Board HiFi Subwoofer |
60W |
24V |
34$ |
G-042 |
|
G-043 |
|
QUEENWAY 1200W +80V-80V Output HI-FI Special Amplifier Switching Power Supply High-power Voltage can be Customized |
1200W |
+80V -80V +-12V +12V |
64$ |
G-043 |
|
G-044 |
|
QUEENWAY Digital Amplifier Power Adapter High Current Output: DC 24V 6A. Input: AC 100-240V Power Supply |
See the details |
24V |
17.3$ |
G-044 |
|
G-045 |
|
QUEENWAY 24V/14.5A 36V/9.5A 48V/7.3A 350W HiFi Digital Amplifier Switching Power Supply |
350W |
24V/36V |
21$ |
G-045 |
|
G-046 |
|
New 1800W 12V Mining Case Power Supply with Low Noise Cooling Fan High Efficiency |
1800W |
12V |
160$ |
G-046 |
